PCB manufacturing capability:
Layer: 1-40 Layers
Board types:
Normal FR-4 PCB, high TG FR-4 PCB, heavy copper PCB, impedance control PCB, high frequency PCB, FPC, rigid-flex
PCB, aluminum PCB, copper based PCB, ceramic based PCB, ultra-thin PCB, and so on.
Surface treatment HASL, RoHS-HASL, Immersion gold, Plating gold, Gold fingers, OSP, Immersion Silver, Chemical Tin
Solder mask colour Green, Blue, Red, Black, Yellow, White
Silk screen colour White, Black, Yellow, Blue, Red, Purple
Tolerance:
Min board thickness tolerance: +/-0.1mm
PTH diameter tolerance: +/-0.05mm
NPTH diameter tolerance: +/-0.025mm
Hole location tolerance: +/-0.05mm
Min outline tolerance: +/-0.1mm
V-cut dept tolerance: +/-0.1mm
Technical Specification:
Min line width/space: 0.05/0.05mm
Min PTH copper thickness: 35um
Min hole diameter: 0.1mm
Min pad ring: 0.05mm
Max copper thickness: 6oz
Max board size: 1200*560mm
Board thickness: 0.1-7.0mm
Solder mask bridge: ≥0.08mm
Aspect ratio: 10:1
Via plugging capacity: 0.2-0.6mm
Board bow and twist: ≤0.5%
Au, Ni, HASL thickness:
1, Immersion gold: Au 1-4u”
2, Gold fingers: Au 1-50u”
3, Plating gold: Au 1-5u”
4, Ni thickness: 100-200u”
5, HASL thickness: 1-50um
6, OSP thickness: 0.3-0.5um
